CV30

Specifications

• Sizes: 2”, 3”, 4” and 6”
• Connections: FNPT (2” Only), Flanged
• Body Type: Globe
• Trim Characteristic: Modified % (Throttling)
• Trim Size: Full Port and Reduced Port (1 Size Down)
• Seat Type: Soft Seat with Metal to Metal Backup
• Pressure Rating: See Literature
• Temperature Range:-50° F to 300° F (-46° C to 149° C)
• Shutoff: ANSI Class VI
• Actuator Sizes:
  • 2” CV30 – #70 (70 in ² area)
    3”,4”, and 6” CV30 – #120 (120 in ² area)
    3”,4”, and 6” CV30 – #260 (260 in ² area) Hercules Actuator
• Actuator Spring Ranges: 3-15 psi, 6-30 psi
• Actuator Action: Reverse (Fail Close) & Direct (Fail Open)
• Stem Travel:
  • 2” CV30 – 1.00in
  • 3” CV30 – 1.42in
  • 4” CV30 – 1.76in
  • 6” CV30 – 2.50in
• Materials:
  • Body: WCC Steel, LCC (Low Temp Option)
  • Packing Plug: A105 Steel with Nickel Plating, A350 LF2 with Nickel Plating (Low Temp Option)
  • Trim:
    • Plug Ring: D2 Tool Steel (Standard), 316 Stainless (Optional), Carbide (Optional)
    • Plug Tip, Seat Ring: D2 Tool Steel, 316 Stainless (Optional)
    • Seat: Polyurethane, Low Temp HNBR (Optional)
  • Cage, Plug, and Stem: 316 Stainless
  • Actuator Housing: Carbon Steel
  • Yoke: A395 Ductile Iron
  • Bolting: A193 B7
